Description
Auxiliary Interface
- SATA1 SATA interfaces
- CapacityUp to 6 TB capacity for each disk
- USB Interface2 × USB 2.0
Network
- Network Interface1, RJ45 10M/100M self-adaptive Ethernet interface
- Remote Connections32
- Network ProtocolsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
Analog Video Input
- Analog Video Input4-ch;BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
- HDTVI Input1080p25, 1080p30, 720p25, 720p30
- AHD Input1080p25, 1080p30, 720p25, 720p30
- HDCVI Input1080p25, 1080p30, 720p25, 720p30
- CVBS InputSupport
- HDMI1/VGA Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- Audio Input1-ch, RCA (2.0 Vp-p, 1 KΩ)
- Audio Output1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ)
Video And Audio
- IP Video Input1-ch (up to 5-ch),Up to 1080p resolution
Recording
- Video CompressionH.264+/H.264
- Encoding ResolutionWhen 1080p lite mode not enabled: 720p/WD1/4CIF/VGA/CIF,When 1080p lite mode enabled: 1080p lite/HD 720p lite/WD1/4CIF/VGA/CIF,
- Frame RateMain stream: ,When 1080p Lite mode not enabled:,For 720p stream access: 720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N),When 1080p Lite mode enabled:,1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N),Sub-stream: ,2CIF@6fps; CIF/QVGA/QCIF@,25fps (P)/30fps (N),
- Video Bit Rate32 Kbps to 6 Mbps
- Dual StreamSupport
- Stream TypeVideo, Video & Audio
- Audio CompressionG.711u
- Audio Bit Rate64 Kbps
General
- Power Supply12 VDC
- Consumption (Without HDD)≤ 8 W
- Working Temperature-10 ºC to +55 ºC (14 ºF to 131 ºF)
- Working Humidity10% to 90%
- Dimensions (W × D × H)260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)
- Weights (Without HDD)≤ 1 kg (2.2 lb)
